OLV-K16 Mini Artımlı (Incremental) Enkoder, 16 mm Dış Çap, 3 mm İçi Boş Mil (Hollow Shaft), 160 – 11520 PPR Çözünürlük, TTL / HTL Çıkış

Name: OLV-K16 Mini Artımlı (Incremental) Enkoder, 16 mm Dış Çap, 3 mm İçi Boş Mil (Hollow Shaft), 160 – 11520 PPR Çözünürlük, TTL / HTL Çıkış
Brand: OLVO
SKU: T1520
Availability: InStock

Ürün Kodu: T1520

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	16mm
Thickness	22.4-25.4mm
Hollow shaft diameter	3mm blind hole
Resolution	160;250;256;300,360;320,500;512;600;640;720;1000;1024;1200;1280;1440;2000;2048;2400;2560;4000;4800;5120;5760;8000;8192;9600;11520
Output phase	Phase A,B,Z
Supply voltage	DC5V ; DC8-30V
Outlettype	Radial cable
	Axial cable
	Radial cable with conector
Output mode	TTL /HTL
Protection grade	IP50
Cable length	1M (cable length could be added appropriately by
Cable length	require, but it need payment individually)
Consumption current	100mA MAX
Top response frenquency	300-500KHZ
Rise/ Fall time	100nsec Max
Shaft load	Radial 2N; Axial 2N
Top REV	6000r rpm
Environmental temperature	Operating:-20 ～+80°；storage:-80～+85°
Enviromental humidity	Operating and storage: 35-95%RH(noncondensing)
Shaft Material	Stainless steel
Shell Material	aluminium alloy
Certification	CE
package	Carton box
Net weight	About 20g (with package)
