OLV-S16 Katı Mil (Solid Shaft) Artımlı (Incremental) Döner Enkoder, 2,6 mm / 3,6 mm / 4,6 mm Mil Çapı, TTL / HTL Çıkış, 4,5 V – 30 V Besleme Gerilimi, 160 – 11520 PPR Çözünürlük Aralığı

Name: OLV-S16 Katı Mil (Solid Shaft) Artımlı (Incremental) Döner Enkoder, 2,6 mm / 3,6 mm / 4,6 mm Mil Çapı, TTL / HTL Çıkış, 4,5 V – 30 V Besleme Gerilimi, 160 – 11520 PPR Çözünürlük Aralığı
Brand: OLVO
SKU: T1519
Availability: InStock

Ürün Kodu: T1519

Teklif

PaylaşKoleksiyonFiyat Alarmı

Brand	SURAL
External diameter	16mm
Solid Shaft Diameter	2/3/4mm
Resolution	160;250;256;300,360;320,500;512;600;640;720;1000;1024;1200;1280;1440;2000;2048;2400;2560;4000;4800;5120;5760;8000;8192;9600;11520
Output phase	Phase A+B+Z+A-B-Z-
Supply voltage	DC5V ; DC4.5-30V
Outlettype	Radial cable
	Axial cable
	Radial cable with conector
Output mode	TTL;HTL
Environmental temperature	Operating:-20 ～+80°；storage:-80～+85°
Environmental temperature	Operating and storage: 35-95%RH(noncondensing)
Top response frenquency	300-500KHZ
Shaft load	Radial 2N; Axial 2N
Top REV	12000r rpm
Rise/ Fall time	100nsec Max
Shaft Load	Radial: 2N; Axial:2N
Shaft Material	stainless steel
Shell	Aluminium Alloy
Package	Carton box
Net weight	About 16g (with package)
Certification	CE
