OLV-S70 Diferansiyel Lineer Uzunluk Ölçüm Cihazı, Pnömatik Sistemler İçin, Artımlı (Incremental) Döner Enkoder

Name: OLV-S70 Diferansiyel Lineer Uzunluk Ölçüm Cihazı, Pnömatik Sistemler İçin, Artımlı (Incremental) Döner Enkoder
Brand: OLVO
SKU: T1531
Availability: InStock

Ürün Kodu: T1531

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	70mm
Thickness	60mm
Installation dimension	Diameter 60mm
Shaft length	16mm
Solid Shaft diameter	8mm(D shape)
Resolution	50; 60; 100; 200; 250; 256; 300; 360; 400; 450; 500; 512; 600
	700; 720; 800; 900; 1000; 1024; 1200; 2000; 2048; 2500; 5000
	8192; 10000; 11520; 16384; 20000; 23040
Output phase	A, B, Z ,A-, B-, Z-
Supply voltage	DC5V&DC8~30V
Usage	automation industry to measure speed or angle
Outlettype	Radial cable
	Radial socket
Output mode	NPN Collector open circuit output
	Voltage output
	Push-pull output
	Difference output	Long line drive( 26LS31)
		Compatible RS422
		Long line drive( RT7272)
Protection grade	IP50 ; IP65
Cable length	1M (cable length could be added appropriately by
	Require, but it need payment individually)
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
Insulation strength	AC500V 60s
Insulation resistance	10MΩ
GND	not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	Less than 5x 10-3 N.m
Intertia moment	Less than 3x 10-6kg.m2
Shaft load	Radial 30N; Axial 20N
Top REV	5000RPM; IP65≤3000r rpm
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating: -20 ~ +80°; storage: -25 ~ +85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm, 5-55Hz,2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Certification	CE
package	Carton box
Net weight	About 450g (with package)
