OLV-S52 Artımlı (Incremental) Üst Düzey Kalite Lineer Enkoder, 1024 PPR, Diferansiyel Çıkışlı

Name: OLV-S52 Artımlı (Incremental) Üst Düzey Kalite Lineer Enkoder, 1024 PPR, Diferansiyel Çıkışlı
Brand: OLVO
SKU: T1527
Availability: InStock

Ürün Kodu: T1527

Teklif

PaylaşKoleksiyonFiyat Alarmı

Items	Basic parameters
Brand	SURAL
Encoder type	Incremental encoder
External diameter	51mm
Thickness	29mm
Installation dimension	Diameter 40mm
Shaft length	16mm
Solid Shaft diameter	8mm(D shape)
Resolution	1000; 1024; 1200; 1250; 1440; 2000; 2048; 2500; 2880; 3000; 3600
	4096; 5000; 5760; 8192; 10000; 11520; 16384; 20000; 23040
	1000/4; 1000/6; 1000/8; 1024/4; 1024/6; 1024/8; 2048/4; 2048/6
	2048/8; 4096/4; 4096/6; 4096/8; 8192/4; 8192/6; /8192/8
Output phase	Phase A+, B+, Z+, A-, B-, Z-, U+, V+, W+, U-, V-, W-
Supply voltage	DC5V; DC8-30V
Outlettype	Cable out from back
	Socket out from back
	Cable out from back with socket
Output mode	NPN&PNP
	Voltage output
	Push-pull output
	Difference output(TTL,HTL,RS422)
Consumption current	100mA MAX
Top response frenquency	300KHZ
Allowable ripple	≤3%rms
Load Voltage	≤DC30V
GND	Not connect to encoder
Mark to Space ratio	45% to 55%
starting torque	Less than 5 x 10-3 N.m
Intertia moment	Less than 3x 10-6kg.m2
Shaft load	Radial 50N; Axial 30N
Top REV	3000RPM; IP65≤2000r rpm
Bearing life	1.5x109 revs at rated load(100000hrs at 2500RPM)
Environmental temperature	Operating:-20 ~ +80°；storage:-25 ~ +85°
Enviromental humidity	Operating and storage: 35-85%RH(noncondensing)
Vibration(endure)	Amplitude 0.75mm, 5-55Hz, 2 hours for three axis individually
Sock(endure)	490m/s2, 11 ms three times for X, Y, Z direction individually
Shaft Material	Stainless steel
Shell Material	Dia cast aluminium
Cable length	1000mm(cable with shielding)
Protection grade	IP50; IP65
Cable length	1M(cable length could be added appropriately by Require, but it need payment individually)

Certification	CE
Package	Carton box
Net weight	About 300g (with package)
